Purpose of the flight and payload description
The objective of the flight was to measure stratospheric water vapor on a long duration balloon mission. The experiment designed by the Service d'Aéronomie of the Centre National de Recherche Scientifique (CNRS) from France was specially adapted to the constrains in weight, power and telemetry impossed by long duration balloons in order to perform observations in the lower stratosphere in particular in the Micronesian region where air enters the stratosphere from the troposphere, an area known as the "Stratospheric Fountain".
At left we can see an scheme of the instrument itself (up) and a diagram of the flight gondola (down). The working principle consisted in observing the fluorescence of the hydroxyl radical OH produced by photodissociation of stratospheric water-vapor by UV radiation. The ultra violet source was an hydrogen lamp manufactured at the SA laboratory, coupled with a Lyman a filter at 122 nm. For redundancy two lamps were used alternatively, which signals were monitored by a nitric oxide ionisation counter (NO counter) mounted in front of the lamps. Fluorescence measurements were made by a photomultiplier working in photon counting mode coupled with two filters centered at 310 nm. Its axis was perpendicular to the UV beam. Due to weight limitations, no turbine to renew the air, and no stainless steel sealed chamber pumped before the flight could be used. To reduce the outgasing contribution, the instrument was placed 200 m below the balloon and 100 m below the service gondola. A flow was insured inside the reaction chamber by the use of an aluminium chimney simply heated by collecting the upwelling infrared radiation from the earth with a thermal cover designed as the MIR itself. Straylight protections were mounted at the two exits of the chimney. The calculated air speed inside the chamber was 50 cm/sec during the night and 150 cm/sec during the day.
The instrument was cycled with a 2 seconds measurement every two minutes, alternatively lamp 1, lamp 2 and dark current. A telemetry message was sent every two minutes including NO counter signal (12 bits),fluorescence signal from the photomultiplier (16 bits), seven temperatures (ambient , photomultiplier, lamp, up-stream and down-stream chamber, electronics and batteries), ambient pressure and batteries voltage. The data were transmitted by HF to two automatic ground receiving stations in South Africa and New Caledonia and to a satellite data collection system providing also balloon locations 5 to 6 times a day (ARGOS).
The MONTGOLFIER INFRARED
The balloon used as platform for this mission is the so called Infrared Montgolfier (MIR) developed by the Service d'Aéronomie of the CNRS and CNES in 1977 in an attempt to meet the needs of long-duration flights. The MIR is a hot air balloon "open at the bottom" made of 2 different materials: a top part of aluminized Mylar 12 µm thick making a cavity for absorbing ascendants infrared and block any re-emission toward the sky and the bottom part made of linear polyethylene 15µm thick, an infrared transparent material and tough at cold (-80°C). It only uses helium to gain altitude at takeoff. Their reflective cover provides lift heating the air inside the envelope by the sun during the day or by the infrared radiation coming from the earth during the night. During the day, the MIR flies at an altitude of about 28 km to 32 km while at night it floats between 18 and 22 km depending on the infrared flux radiating from the overflown area and the temperature of the air parcel. It could carry a scientific payload of about 50 kg.
Details of the balloon flight
Balloon launched on: 7/26/1985 at
Launch site: Paardefontein Tracking Station, Pretoria, Southafrica
Balloon launched by: Centre National d'Etudes Spatiales (CNES)
Balloon manufacturer/size/composition: Montgolfier Infrared 36.000 m3
End of flight (L for landing time, W for last contact, otherwise termination time): 8/10/1985 at ??
Balloon flight duration (F: time at float only, otherwise total flight time in d:days / h:hours or m:minutes - ): 15 d
Landing site: Payload recovered In the chilean Patagonia.
The balloon was launched from the grounds of the Satellite Tracking Station of CNES in Paardefontein, near Pretoria on July 26, 1985. It started an eastbound flight path across the Indian Ocean and the Pacific Ocean until it came down in the Chilean Patagonia after 15 days of flight. Due to telemetry problems, scientific data were transmitted only 10 days. After separation of the payload the MIR continued flying above the Atlantic Ocean until wind reversal returned it to southamerican coasts appearing above Buenos Aires and nearby cities on September 17, 1985 causing great impact and an infamous UFO case known as "El OVNI del 17" (spanish for "the UFO of 17th") which still today, generates a though debate. In the references below there is a link to a dossier I've wrote many years ago about that UFO case. The research I've made along five years regarding that sighting eventually led to the creation of this website.
- Campagne de lachers de montgolfieres infrarouges COSPAR Information Bulletin, 1986(105), 77
- Cronica de un OVNI que no fue / Chronicle of a UFO that was not Dossier (in spanish) about the UFO case of September 17, 1985 above Buenos Aires, Argentina
- La Montgolfiere infrarouge: Acquis et futur Advances in Space Research, Volume 7, Issue 7, p. 59
- Stratospheric water vapor in-situ measurements from infra-red montgolfier Advances in Space Research, 7(7), 111
